.Su-24MR '08'
Page précédente (p)Page précédente (p) On can distinguish the MAK-UL IR missile warning system on top of the fuselage of this Su-24MR being prepared for another flight on the Welzow flightline. The antennas on the air intake (above the bort number) and on top of the fin (right above the smaller bort number) were related to the SPO-15 RHWR. A transponder antenna was protruding above the rudder and an ILS antenna was located below it. Note the spare parachutes on the trolley.
